Online 1500VA 120VAC
Input Cord: 6ft NEMA 5-15P
Output Receptacles: (8) NEMA 5-15R
- High output power factor
- Up to 98% efficient operation
- Extended battery packs available for 2U models
- Multiple communications capability
- Hot swappable battery design
- Programmable outlet groups (2U)
- $50,000 load protection policy
- UL, cUL, RoHS, FCC Class B (1000VA (2U), 1500VA),
- FCC Class A (1000VA (1U), 2000VA, 3000VA, TAA compliant (UPS only)
- 3 years electronics, 3 years battery warranty (USA and Canada)
XPC P91-1500 UPS
SKU: 90000622
$1,520.00Price
First file
Second file
Third file
Category Specification Capacity 1500VA (1450W) Input Voltage/Frequency 55–150VAC / 50/60Hz auto-sensing Output Voltage 120VAC nominal (100/110/115/127 selectable) Waveform ≤2% THD (linear load), ≤4% THD (non-linear load) Frequency 50/60Hz ±0.1Hz Efficiency Up to 98% ECO or 94% online mode Overload Capacity >110% & ≤130% for 5 min; >130% & ≤140% for 30 sec; >140% for 1.5 sec Battery Chemistry Sealed, maintenance-free lead acid Battery Size (3) 12V 9AH Recharge Time <3 hours to 95% with 2A charger Charging Current 2A default, max 8A adjustable Dimensions (W×D×H) 17.2×19×3.5 in Weight 34.2 lbs Line Cord 6ft, 5–20P Receptacles (8) NEMA 5-15/20R Operating Temperature 32–104°F (0–40°C) Altitude 11,500 ft above sea level Approvals UL, cUL, RoHS, FCC Class B (1000VA, 1500VA) Warranty 3 years electronics, 3 years battery (USA/Canada) Interface RS-232(2U), USB, EPO, intelligent slot (Web/SNMP, Relay/Dry contact, Modbus) Included in Box ViewPower software, front brackets, tower pedestals, user manual Available Options Bypass distribution (XBDM), power distribution (XPDU), 4-post rail kit, 2-post shelf kit, wall mount bracket (2U units)
