Online 1500VA 120VAC
Input Cord: 6ft NEMA 5-15P
Output Receptacles: (8) NEMA 5-15R
High output power factor
Up to 98% efficient operation
Extended battery packs available for 2U models
Multiple communications capability
Hot swappable battery design
Programmable outlet groups (2U)
$50,000 load protection policy
UL, cUL, RoHS, FCC Class B (1000VA (2U), 1500VA),
FCC Class A (1000VA (1U), 2000VA, 3000VA, TAA compliant (UPS only)
3 years electronics, 3 years battery warranty (USA and Canada)
XPC P91-1500 UPS
Category
Specification
Capacity
1500VA (1450W)
Input Voltage/Frequency
55–150VAC / 50/60Hz auto-sensing
Output Voltage
120VAC nominal (100/110/115/127 selectable)
Waveform
≤2% THD (linear load), ≤4% THD (non-linear load)
Frequency
50/60Hz ±0.1Hz
Efficiency
Up to 98% ECO or 94% online mode
Overload Capacity
>110% & ≤130% for 5 min; >130% & ≤140% for 30 sec; >140% for 1.5 sec
Battery Chemistry
Sealed, maintenance-free lead acid
Battery Size
(3) 12V 9AH
Recharge Time
<3 hours to 95% with 2A charger
Charging Current
2A default, max 8A adjustable
Dimensions (W×D×H)
17.2×19×3.5 in
Weight
34.2 lbs
Line Cord
6ft, 5–20P
Receptacles
(8) NEMA 5-15/20R
Operating Temperature
32–104°F (0–40°C)
Altitude
11,500 ft above sea level
Approvals
UL, cUL, RoHS, FCC Class B (1000VA, 1500VA)
Warranty
3 years electronics, 3 years battery (USA/Canada)
Interface
RS-232(2U), USB, EPO, intelligent slot (Web/SNMP, Relay/Dry contact, Modbus)
Included in Box
ViewPower software, front brackets, tower pedestals, user manual
Available Options
Bypass distribution (XBDM), power distribution (XPDU), 4-post rail kit, 2-post shelf kit, wall mount bracket (2U units)
